V-DB500 Industrial Metal Shredder | VANEST MACHINERY
Home      Products     Industrial Metal Shredders       V-DB500 Industrial Metal Shredder
  • V-DB500 Industrial Metal Shredder

V-DB500 Industrial Metal Shredder

  • On-site installation by professional technicians.
  • Installation appointments available.

VANER V-DB500 Twin-Shaft Industrial Shredder

15 RPM Low-Speed Design | Dual 7.5 kW Motors | 24 High-Strength Blades

The VANER V-DB500 is a twin-shaft industrial shredder designed to reduce the size of suitable solid waste and recyclable materials. Its dual-shaft cutting system delivers low-speed, high-torque shearing performance for a range of recycling and material-reduction applications.Powered by two 7.5 kW motors and equipped with 24 high-strength blades, the V-DB500 is built for reliable operation in recycling facilities and industrial workshops.


Key Features
● Low-Speed, High-Torque Design: Operates at 15 rpm to provide strong shearing force with reduced operating noise.
● Dual-Motor Drive: Two 7.5 kW motors power the shredding system. Durable Cutting Blades: Special alloy tool steel blades are precision-machined and heat-treated for wear resistance.
● Durable Cutting Blades: Special alloy tool steel blades are precision-machined and heat-treated for wear resistance.
● Overload Protection: Reverse and automatic overload protection functions help manage certain overload conditions.
● Emergency Braking: An emergency braking function helps improve operational safety.
● Heavy-Duty Construction: A robust frame and sealing structure are designed for demanding shredding applications.

Suitable Applications
The V-DB500 may be suitable for processing:
● Wood: Timber, wooden boards, and old furniture
● Plastics: Plastic drums, containers, and other suitable plastic waste
● Textiles: Suitable fibers, and fabrics
● Paper and Packaging: Cardboard, paper, woven bags, and plastic film
● Electronic Waste: Selected electronic components and appliance housings
● Mixed Waste: Certain mixed materials, subject to material assessment and machine configuration
Batteries, scrap metal, and other challenging materials may require specific configurations or additional safety measures. Please confirm suitability with our team before processing.

How Does It Work?
Two rotating shafts fitted with cutting blades work together to shear incoming materials into smaller pieces. The output size depends on blade design, cutter configuration, material properties, and operating conditions.

Find the Right Shredder for Your Material
To help us assess whether the V-DB500 suits your needs, please provide:
● Material type: What do you need to shred?
● Material dimensions: What are the approximate size and thickness?
● Target output size: How small do you need the material to be?
Send us photos or a video of your material for an initial assessment.

Contact VANER today for technical details and a quotation.
Model V-DB300 V-DB400
V-DB500 V-DBK600 with PLC V-DBK800 with PLC
Motor 3KW(2 units)
4KW(2 units) 7.5KW(2 units) 11KW (2 units) 22KW (2 units)
Voltage 3phase/1Phase - Plug 3phase/1Phase - Plug 380v 50hz 3phase 380v 50hz 3phase 380v 50hz 3phase
Input rotary speed 16rpm/min 15rpm/min 15rpm/min 16rpm/min 16rpm/min
Feeding hole size 500*500mm 600*500*300mm 700*600*300mm 1000*800*500mm 1500*1000*600mm
Blades quantity 24 pieces 26 pieces 24 pieces 29 pieces 26 pieces
Machine size (L*W*H) 1420*570*1429mm 1540*600*1450mm 1840*700*1600mm 1860*920*1800mm 2280*1160*2220mm
Machine weight 500KG 800KG 1000KG 1800KG 3000KG
